E-7A WEDGETAIL Airborne Early Warning & Control aircraft




E-7A WEDGETAIL Airborne Early Warning & Control aircraft technical data sheet specifications intelligence description information identification pictures photos images video Australia Australian Air Force defence aviation aerospace industry technology
Description

The first E-7A Wedgetail Airborne Early Warning & Control (AEW&C) aircraft was delivered to Australia in 2009 and began operations in 2010. A total of 6 aircraft have been delivered to Australia. The E-7A Wedgetail represents an entirely new capability for the ADF (Royal Australian Air Force), providing a platform that will gather information from a wide variety of sources, analyse it and distribute it to all friendly air and surface assets. AEW&C aircraft can control the tactical battle space, providing direction for fighter aircraft, surface combatants and land based elements, as well as supporting aircraft such as tankers and intelligence platforms. The E-7A Wedgetail is therefore a major new capability for the Australian Defence Force, which will significantly multiply the effectiveness of our existing Navy, Army, Air Force and Coastwatch, and help Australia maintain a capability edge well into the future. The E-7A Wedgetail is truly the “Eyes of the Nation”.


Main Variants
- No variants.

Technical Data
Back menu
Design
Based on the 737-700 commercial airliner airframe, the E-7A features advanced multirole electronically scanned radar and 10 state-of-the-art mission crew consoles that are able to track airborne and maritime targets simultaneously.
Avionics an equipment
The E-7A Wedgetail is equipped with ventral fins to counterbalance the radar and countermeasures mounted on the nose, wingtips and tail. In-flight refueling is via a receptacle on top of the forward fuselage. The cabin features eight operator consoles with sufficient space for four more; the Australian fleet will operate ten consoles with space for two more (four on port side and six on the starboard side).
- Multi-role electronically scanned array (MESA) radar with range in excess of 400km
- Electronic warfare self-protection measures including directed infra-red counter-measures, chaff and flares
- Communication systems including HF, VHF, UHF, Link-11, Link-16, UHF SATCOM and ICS
Propulsion
The E-7A Wedgetail is powered by two CFM International CFM56-7B24 engines, each rated at 118kN. The aircraft has a flying boom receptacle and a fixed probe providing dual in-flight refuelling capability. The CFM56-7B24 engine is also equipped with dual annular combustor for low emissions capability, common core and low pressure turbine. The E-7 Wedgetail operates at an altitude of 30,000ft to 40,000ft with a maximum operating altitude of 41,000ft. The maximum dash and normal cruise speed of the aircraft are 955km/h and 759km/h respectively. The range is 7,040km and the service ceiling is 12,500m.
Missions
AEW&C aircraft elevate the radar 10,000 metres above the earth’s surface so that the radar can ‘see’ everything out to a range of hundreds of kilometres. Low flying aircraft can no longer ‘sneak up’ by approaching below the radar horizon. An E-7A Wedgetail cruising at an altitude of 10,000 metres can maintain surveillance over a surface area of 400,000 square kilometres at any given time. Over a 10-hour mission, the Wedgetail could cover over 4 million square kilometres. The radar is capable of simultaneous air and sea search, fighter control and area search, with a maximum range of over 600 km (look-up mode). When operate in look-down mode against fighter-sized target, the maximum range is in excess of 370 km. When used against maritime targets, the maximum range is over 240 km for frigate-sized targets. MESA is capable of simultaneously tracking 180 targets and conducting 24 intercepts. In addition, the radar antenna array is also doubled as an ELINT array, with a maximum range of over 850 km at 9,000 meter altitude

Specifications
Type
Airborne early warning and control aircraft
Country user
Australia
Country producer
United States
Crew
Pilot, co-pilot and airborne electronics analysts and mission specialists (10 mission consoles)
a
Engine
2 × CFM International CFM56-7 turbofans (118.4kN (27,300lb) thrust each)
Speed
Maximum speed: 955km/h
Range
760 km maximum
Weight
3,585 kg take-off
Avionics and equipment
Multi-role electronically scanned array (MESA) radar, Electronic warfare self-protection measures, Communication systems
Dimension
Length: 33.06 m; Wingspan: 35.8 m;
Height: 12.5 m
