Some aspects of the No-dong-A seems to bear a close design resemblance to the early Soviet SS-N-4/R-13 and SS-N-5/R-21 (SLBM) Submarine-launched Ballistic Missile designs. The Soviet R-13, known in the West as the SS-N-4, used one Isayev S2.713 engine with larger 1.3 m diameter tankage from the Scud 0.88 m diameter tankage design and warhead separation from the missile body. This missile had a launch weight of 13,745 kg, a range of 560 km and a body diameter of 1.3 meters. And the R-21, designated the SS-N-5 used the four thrust chamber Isayev S-5.38 higher thrust engine and more tankage with perhaps a airframe material tankage materials change and rearranged propellant tanks along with warhead separation. With a body diameter of 1.4 m, this missile had a launch mass of nearly 19,653 kg. with a range of 1,420 km. The No-Dong-A missile has a range of approximately 1,000 - 1,300 km. The accuracy of the missile is believed to be 2,000 - 4,000 m CEP when deployed at maximum range. The No-dong-A has a reported mass of 15,200-16,000 kilograms, with a diameter of 1.32-1.35 m's and a length of 15.895 m. The missile can be equipped with a 1,200 kg separating warhead that can deploy 800 kg of HE-unitary, chemical, submunitions, biological, or medium-yield nuclear weapons. A nuclear warhead development program was started in 1990 which may include warheads for the No Dong missiles. A North Korean statement in 2002 suggested that their scientists had assembled between 2 and 5 nuclear warheads; potentially, some of those were fitted to the No Dong 1 missiles.
|
|
Type of missile
|
|
medium range ballistic missile
|
|
Country users
|
|
North Korea
|
|
Launcher
|
|
mobile truck transporter - erector - launcher
|
|
Warhead
|
|
nuclear, chemical, conventional HE, submunitions
|
|
Crew
|
|
?
|
|
|
Vehicle weight
|
|
? kg
|
|
Effective range
|
|
1,000 to 1,300 km.
|
|
Accuracy
|
|
2,000 - 4,000 CEP
|
|
Guidance
|
|
Inertial system and upgrade with GPS system
|
|
Dimensions vehicle
|
|
Length, ? m; Width, ? m; Height, ? m
|
|
|
